160 g/m² Dyneema® Fabric Twill | SP-T160DY
Dyneema® Fabric Twill | SP-T160DY
** Special items from larger industrial production **
Technical data:
Weight: 160 g/m²
Weave: Twill 2/2
Sizing: stuhlroh
Width: 100 cm
Technical data:
Weight: 160 g/m²
Weave: Twill 2/2
Sizing: stuhlroh
Width: 100 cm
Yarn type specifications:
Warp: 18 y/cm (44 tex)
Warp: 18 y/cm (44 tex)
Weft: 18 y/cm (44 tex)
Description:
Dyneema® is known as the ‘strongest fibre in the world’. It has one of the lowest densities of any reinforcement fibre and the highest specific strength in relation to weight, as well as very good impact resistance. Despite corona treatment, however, the fabric has relatively low adhesion to the resin matrix.
Areas of application:
Dyneema® fabrics are ideal for ballistic applications such as armour, military helmets and bulletproof vests, and are resistant to mechanical wear and friction. However, this also makes them almost impossible to cut with standard scissors. Furthermore, they are resistant to many chemicals, salt water and UV radiation. Ideal for outdoor and marine applications.
Delivery notes for this product:The lengths of the rolls vary! Therefore, a position of 10m² or more may consist of several rolls.
Working Notes:
In this instruction you will find tips & tricks by working with glass fiber fabrics and epoxy resins:
Boat Building (PDF)
Laminate Calculator:
Here you can calculate specific values for different fibers, resins and processes:
Laminate Calculator
Laminate Calculator
Characteristics of Glass Fabric Constructions:
Glass Fabrics are available in different constructions. The important characteristics you will find below:
Plain
|
|
Twill
|
|
Satin
|
|
