310 g/m² Aramid Fabric Twill | HP-T310A

Name: 310 g/m² Aramid Fabric Twill | HP-T310A
SKU: HP-T310A
Price: 31.89 EUR
Availability: InStock

Product No.:: HP-T310A
Shipping time:: ca. 1-3 days (abroad may vary)
Stock:: m²

Sliding scale prices

1-2,5 m²: per 31,89 EUR
3-4,5 m²: per 29,69 EUR
5-9,5 m²: per 27,97 EUR
10-24,5 m²: per 26,48 EUR
25-49,5 m²: per 24,93 EUR
50-99,5 m²: per 23,21 EUR
> 99,5 m²: per 22,37 EUR

31,89 EUR

incl. 19% tax excl. Shipping costs

m²:

Add to wish list

Ask about product

Description

Aramid Fiber Fabric Twill | HP-T310A

Weight: 310 g/m²
Weave: Twill 2/2
Width: 100 cm

Yarn type specifications:
Warp: 4,6 y/cm (316 tex)

Weft: 4,6 y/cm (316 tex)

Thickness: 0,61 mm

** The length of the rolls may vary. Therefore it is possible that a position from 10m² consists of several rolls. **

Areas of application:

Ship and boat construction, modelling, aircraft construction, sports equipment making, motor sport, ...

Properties Aramid Fiber:
Aramid fibres are characterized by a high tenacity, a very good impact strength and abrasion resistance. Further properties are e.g. a good dampening ability, excellent chemical resistance and non-flammability.

Calculated data for hand laminate with 35 volume percent fibres:
Resin consumption: 456 g/m²
Laminate thickness: 0,61 mm
Laminate weight: 767 g/m²

► Laminate calculator
Here you can calculate specific values for the vacuum infusion.

Working Notes & Support

Laminate Calculator:

Here you can calculate specific values for different fibers, resins and processes:
Laminate Calculator

Characteristics of Aramid Fabric Constructions:

Aramid Fabrics are available in different constructions. The important characteristics you will find below:

Plain

The simplest weave
Very slip-resistant
Bad drapability
Suitable for flat plates or easy moulds

Twill

Diagonally running lines are characteristic
Better drapability than plain weave
Less slip-resistant
Suitable for complicated geometries
