83 g/m² Peel Ply Plain (Width: 10 cm) | HP-P83P10

Product No.:
HP-P83P10-H
Shipping time:
ca. 1-3 days ca. 1-3 days (abroad may vary)
Sliding scale prices
1-2 Piece
per 29,20 EUR
3-4 Piece
per 25,00 EUR
5-9 Piece
per 21,70 EUR
> 9 Piece
per 19,20 EUR
29,20 EUR

incl. 19% tax excl. Shipping costs

Add to wish list
Ask about product
Description

83 g/m² Peel Ply Plain (Width: 10 cm) | HP-P83P10

It is made of Nylon and is added into epoxy- or polyester resins as the first and/or last layer of the construction. After hardening, just before further processing it has to be peeled of slowly and in a sharp angle. The Peel Ply leaves an evenly rough, lubricant film free and adhesive surface behind. Sanding or cleaning of the surface is not necessary before sticking or coating. The Peel Ply can´t remain in the construction therefore is a red or blue tracer thread woven into the fabric.

Weight: 83 g/m²
Weave: Plain
Width: 10 cm
Length: 100 mtr.
Material: Nylon 6.6 cleaned

Yarn type specifications:
Warp: 19 y/cm
Weft: 16 y/cm

Technical Data Sheet Carbon Fabric HP-P200C


Advantages of Peel Ply Fabric:

  • Accurate upper surface
  • A bit rough after tearing off, absolutely clean and free of dust
  • Ideal subsoil for bonding or further laminating/painting
  • Saves time, no need to grind with sand-paper or removing of grinding dust
In some cases it is desired to have a slip resistance of the component (e.g. stand space of surf boards, boat decks). The surface is after tearing the Peel Ply off ready for use.


► Laminate calculator
Here you can calculate specific values for the vacuum infusion.

Working Notes & Support

Working Notes:
In this instruction you will find tips & tricks by working with reinforcement fabrics:
Boat Building (PDF)

further working notes you will find here


Laminate Calculator:
Here you can calculate specific values for different fibers, resins and processes:
Laminate Calculator



Characteristics of Peel Ply Constructions:

Peel Ply are available in plain or twill. The important characteristics you will find below:

Plain
Plain
  • The simplest weave
  • Very slip-resistant
  • Bad drapability
  • Suitable for flat plates or easy moulds

Twill
Twill
  • Diagonally running lines are characteristic
  • Better drapability than plain weave
  • Less slip-resistant
  • Suitable for complicated geometries
