Infusion System - Epoxy - Hardener component | HP-HTE200GL
Vacuum Infusion, Pressure Injection | Epoxy - Hardener HP-HTE200GL
The hardener HP-HTE200GL allows a pot-life of 200 minutes. The basis of the series HP-E3000GL is an unfilled epoxy-resin, which is mixable with different hardeners for every individual purpose. A special feature of this series is a high initial glass transition temperature (Tg) by hardening at room temperature.The use of the hardener HP-E200GL increases the maximum glass transition temperature (Tg MAX) up to 107°C.
The series also has a high transparency so that it is very suitable for visible carbon parts.
Here you will find the suitable resin
Features & Benefits:
- Extremely low viscosity, so it has a very good fibre wet-out
- Pot life time can be freely adjusted between 15 minutes (hardener HP-E15GL) and 300 minutes (hardener HP-E300GL)
- Glass transition temperature (Tg max) up to 107 °C (hardener HP-E200GL)
- High static and dynamic strength
- Vacuum-infusion methods (IMC/MTI, RI, VARI, SCRIMP®,…)
- Pressure injection methods (RTM, RIM,…)
- Filament winding
- Hand laminating
- Optical application such as visible carbon parts (hardener HP-E200GL)
Product Properties Epoxy Resin HP-HTE200GL
- Colouring: trasnparent
- Mixing ratios: 100 parts resin / 30 parts hardener (by weight)
- Working Time (pot life): 200min (at 20°C or 68°F)
- Working Temperature: 20 °C
Working notes and decision guidance for Epoxy Resins
Below you will find processing information for epoxy resins, safety notes and also a decision guide for helping choosing the correct epoxy system.Practical tips for epoxy resins (PDF)
Epoxy resin for boat building (PDF)
Decision guidance epoxy resins (PDF)
Hazard Statements
Hardener: Safety data sheet (PDF)
Caution
H302 Harmful if swallowed.
H314 Causes severe skin burns and eye damage.
H317 May cause an allergic skin reaction.
H373 May cause damage to organs through prolonged or repeated exposure.
H412 Harmful to aquatic life with long lasting effects.
