Carbon braided Sleeve 6K (D= 18 mm at 45°) | HP-BSC018/32/6
Carbon braided Sleeve 6K (D= 18 mm at 45°) | HP-BSC018/32/6
The diameter of the braided sleeves can be varied by stretching. Ideally, the fiber angle should be between 30° and 60°. Optimal torsion and shear strengths are achieved at an angle of 45°. You can find more detailed information on our product data sheet.Material: 6K 400tex (HT-Fibre)
Number of ends: 32
Diameter at 45°: 18 mm
Area of applications: 7 -24 mm
| Angle: | 45° | stretched condition |
| Width flat: | 28,00 mm | 8,00 mm |
| Weight: | 18,10 g/m | 13,00 g/m |
| Weight m²: | 646,50 g/m² |
Areas of applications:
Tanks, pipes, hulls, model making, boat construction, sport equipment, repairs & reinforcements, ...
Delivery notes for this product:Our carbon braided tapes are always offered and sold in stretched condition, since it is technically not possible to wrap the tapes with a fiber angle of 45°.
Due to the current export regulations it is not possible to ship this product outside the EU!
